B7060TTNR-12
GVWR |
7,000# |
AXLE |
2 – 3,500# DEXTER AXLE W/BRAKES |
SUSPENSION |
EYE TO EYE SPRING |
COUPLER |
2″ |
SAFETY CHAINS |
1/4′ W/GRAB HOOK |
JACK |
2,000# TOP WIND |
TONGUE/NECK |
4″ C-CHANNEL |
FRAME |
3″X3″X1/4″ ANGLE |
CROSSMEMBERS |
3″X2″X3/16 ANGLE |
RAMPS |
OPTIONAL / DOVETAIL |
SIDE / TOP RAIL |
2″ SQUARE TUBE |
FLOOR |
TREATED WOOD |
FENDERS |
TREADPLATE STEEL SQUARE BROKE |
WHEELS |
15″ |
TIRES |
ST205/75R15 |
LIGHTS |
100% LED |
WIRING |
SEALED WIRING HARNESS |
ELECTRICAL PLUG |
7-WAY RV |
FINISH |
PREP / PRIMED / PAINTED |
Additional Models |
||
| B7060TTNR-14 | 60″x14′ 7,000# GVWR | |
| B7060TTNR-16 | 60″x16′ 7,000# GVWR | |
| B7077TTNR-12 | 77″x12′ 7,000# GVWR | |
| B7077TTNR-14 | 77″x14′ 7,000# GVWR | |
| B7077TTNR-16 | 77″x16′ 7,000# GVWR | |
| B7083TTNR-12 | 83″x12′ 7,000# GVWR | |
| B7083TTNR-14 | 83″x14′ 7,000# GVWR | |
| B7083TTNR-16 | 83″x16′ 7,000# GVWR | |
Options |
| Tire Upgrade |
| Tread Plate Decking |
| Rumber Decking (12″xmembers) |
| Expanded Metal Sides Std Height |
| Solid Metal Sides Std Heights |
| 24″-48″ Sides |
| Aluminum Tongue Box |
| Swivel Jack |
| 4′ Ramp Gate |
| 4′ Bi-Fold Ramp Gate |
| Spring Loaded Ramp Gate |
| 2′ Dovetail with 3′ Ramp Gate Slide In Ramps |
| Spare |
| Hunter Special Package |
| Chrome Bike Chock |
| Electric Jack W/ Battery |
